UA-VOLT4PMAX
Universal Audio UA Volt 4P Max USB Audio Interface 12-in/6-out
Pay With
Product Information
The Universal Audio Volt 4P Max is a flagship 12-in / 6-out desktop USB audio interface designed for bands, drummers, producers, engineers, podcasters, and content creators who need expanded recording capability with professional studio sound. Featuring four Tone Shaping Preamps, Max compression, 32-bit / 192 kHz conversion, speaker switching, a built-in talkback microphone, full-colour Smart Display, Auto-Gain, Clip Protection, ADAT expansion, MIDI I/O, and a comprehensive UAD software bundle, Volt 4P Max is built to handle larger recording sessions with ease.
Built by the same Universal Audio team behind the legendary Apollo interfaces, Volt 4P Max features four digitally controlled mic preamps with 60 dB of available gain and three harmonic character modes — Warmth, Focus, and Shine. These provide Tube, Solid State, and British Class-A-inspired tonal options, allowing you to add rich analog-style character to vocals, guitars, drums, and other instruments directly at the source.
Max Processing adds onboard real-time compression with six musical presets designed for vocals, guitars, bass, and other sources. Inspired by classic studio compressors including the LA-2A and 1176, Max Processing can be combined with the three Tone Shaping modes to provide more than 18 tonal combinations directly from the interface.
Four mic / line inputs allow up to four sources to be recorded at once, making Volt 4P Max ideal for recording bands, drum setups, multiple vocalists, and larger sessions. Two front-panel Hi-Z instrument inputs provide convenient direct connection for guitars and basses, while independent 48V phantom power is available on each microphone channel for condenser microphones.
For larger studio systems, Volt 4P Max includes ADAT or S/PDIF optical input, allowing up to eight additional digital channels at 44.1 or 48 kHz. MIDI In and Out provides connectivity for keyboards, synthesisers, drum machines, and controllers, while the onboard USB hub can connect and power compatible peripherals.
The full-colour Smart Display provides detailed visual feedback for inputs, recording levels, settings, and gain reduction. Auto-Gain automatically sets suitable recording levels in seconds, while Clip Protection catches unexpected peaks to help keep your recordings clean and distortion-free.
Two stereo monitor outputs provide Main and Alt speaker switching, making it easy to compare mixes across two sets of studio monitors. Two studio-quality headphone outputs support monitoring and collaboration, while the built-in talkback microphone provides convenient communication with performers during recording sessions.
Built-in Loopback makes Volt 4P Max ideal for multi-guest podcasts, livestreams, video calls, and content creation by allowing live sources to be combined with computer audio. Full integration with the UAD Console app and LUNA provides session recall and low-latency cue mixes for a streamlined professional workflow.
Volt 4P Max also includes the UAD Volt Studio Bundle and a comprehensive collection of third-party software, providing professional EQs, compressors, reverbs, guitar and bass amps, instruments, and production tools right out of the box.
Features
- Flagship 12-in / 6-out desktop USB audio interface with professional 32-bit / 192 kHz audio conversion
- Four Tone Shaping Preamps with 60 dB of digitally controlled gain
- Three preamp character modes: Warmth, Focus, and Shine
- Warmth mode provides tube-inspired tonal character
- Focus mode provides solid-state-inspired tonal character
- Shine mode provides British Class-A-inspired tonal character
- Max Processing with six onboard real-time compression presets
- Compression presets inspired by classic LA-2A and 1176 studio compressors
- More than 18 tonal combinations using Tone Shaping and Max Processing together
- Four mic / line inputs for recording up to four sources simultaneously
- Two front-panel Hi-Z instrument inputs
- Independent 48V phantom power on each microphone channel
- Ideal for recording bands, drums, vocals, guitars, and multiple performers
- Speaker switching between Main and Alt monitor outputs
- Built-in talkback microphone for studio communication
- ADAT or S/PDIF optical input for digital expansion
- Up to eight additional digital input channels via ADAT at 44.1 or 48 kHz
- MIDI In and Out for keyboards, controllers, drum machines, and synthesisers
- Onboard USB hub for connecting and powering compatible peripherals
- Full-colour Smart Display with gain-reduction metering
- Auto-Gain automatically sets suitable recording levels
- Clip Protection helps prevent unexpected peaks from ruining takes
- Two studio-quality headphone outputs with one shared cue mix
- Built-in Loopback for podcasting, streaming, and content creation
- Full integration with UAD Console and LUNA
- Session recall and low-latency cue mix support
- USB bus powered and class compliant
- Compatible with Mac, Windows, iPad, and iPhone
- Rugged desktop construction designed for long-term studio use
Included Software
- LUNA Digital Audio Workstation: Universal Audio's recording, mixing, and mastering environment
- Topline Vocal Tune: Vocal tuning software included with the UAD Volt Studio Bundle
- UA 610 Tube Preamp & EQ Collection: Classic UA tube preamp and EQ emulation
- Century Tube Channel Strip: Tube channel strip for recording and mixing
- Teletronix LA-2A Tube Compressor: Classic optical tube compression
- UA 1176 Classic FET Compressor: Classic FET compression
- Pure Plate Reverb: Plate-style reverb effect
- Galaxy Tape Echo: Vintage-inspired tape echo effect
- Oxide Tape Recorder: Tape recording emulation
- Vibe Analog Machines: Analog-inspired processing tools
- PolyMAX Synth: Polyphonic software synthesiser
- Anthem Analog Synth: Analog-style software synthesiser
- UAD Lion '68 Super Lead Amp: Guitar amplifier plug-in
- UAD Showtime '64 Tube Amp: Vintage-style tube guitar amplifier plug-in
- Melodyne Essential by Celemony: Pitch and timing editing software
- Ampeg SVT-VR Classic Bass Bundle by Plugin Alliance: Includes Ampeg SVT-VR Classic, bx_Tuner, and bx_Masterdesk_Classic
- Virtual Drummer DEEP by UJAM: Virtual drum instrument
- Virtual Bassist DANDY by UJAM: Virtual bass instrument
- Splice INSTRUMENT: Included virtual instrument
- Prisma - Producer Lab by UVI: Included UVI production software
- FL Studio Producer Edition: Three months free
Specifications
- Brand: Universal Audio
- Model: Volt 4P Max
- Product Type: USB Audio Interface
- Simultaneous I/O: 12-In / 6-Out
- Maximum Audio Resolution: 32-Bit / 192 kHz
- Supported Sample Rates: 44.1, 48, 88.2, 96, 176.4 and 192 kHz
- Bit Depth: 32-Bit
- Microphone Preamps: 4
- Microphone Preamp Gain: 60 dB
- Preamp Processing: Tone Shaping, Harmonic Saturation and Max Compression
- Preamp Character Modes: Warmth, Focus and Shine
- Max Processing Presets: 6
- Mic / Line Inputs: 4 x XLR / 1/4" Combo Jack
- Instrument Inputs: 2 x Front-Panel 1/4" TS Hi-Z
- Phantom Power: +48V Switchable Per Channel
- Monitor Outputs: 2 x Stereo Pairs with Main / Alt Speaker Switching
- Additional Line Outputs: Line 3-4
- Headphone Outputs: 2 x Stereo Outputs with One Shared Cue Mix
- Talkback: Built-In Microphone
- Optical Input: ADAT or S/PDIF
- ADAT Input: 8 Channels at 44.1 / 48 kHz, 4 Channels at 96 kHz, 2 Channels at 192 kHz
- S/PDIF Input: 2 Channels at All Supported Sample Rates
- MIDI: MIDI In / Out
- MIDI Connector: 1/8" TRS Mini-Jack, Type A
- Smart Display: Full-Colour Display with Gain-Reduction Metering
- Auto-Gain: Yes
- Clip Protection: Yes
- Loopback: Yes
- USB Host: USB 2.0
- USB Hub: 1 x Peripheral Port, 5VDC @ 0.5A Maximum
- USB External Power Input: USB Type-C, 5VDC @ 2A Minimum
- Included External Power Supply: 5VDC @ 3A
- USB Connector Type: USB Type-C
- USB Bus Powered: Yes
- Power Consumption: 6.0W Typical / 9.1W Maximum
- Power Switch: Rear Panel
Instrument Input Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.02 dB
- Dynamic Range: 116 dB A-Weighted
- THD + Noise: -108 dB (0.0004%)
- Maximum Input Level: 13 dBu
- Input Impedance: 1 MΩ
- Available Gain: 60 dB Digitally Controlled
- Connector: 1/4" TS Unbalanced
Microphone Input Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.08 dB
- Dynamic Range: 119 dB A-Weighted
- THD + Noise: -108 dB (0.0004%)
- Maximum Input Level: 14 dBu
- Input Impedance: 2 kΩ
- Available Gain: 60 dB Digitally Controlled
- Phantom Power: +48V Switchable Per Channel
- Connector: XLR Combo Jack, Pin 2 Positive
Line Input Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.05 dB
- Dynamic Range: 119 dB A-Weighted
- THD + Noise: -108 dB (0.0004%)
- Maximum Input Level: 22 dBu
- Input Impedance: 10 kΩ
- Available Gain: 60 dB Digitally Controlled
- Connector: 1/4" TRS Balanced or TS Unbalanced via Combo Jack
Monitor & Line Output Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.05 dB
- Dynamic Range: 126 dB A-Weighted
- THD + Noise: -112 dB (0.0003%)
- Maximum Output Level: 20.2 dBu
- Output Impedance: 200 Ω
- Connector: 1/4" TRS Balanced or TS Unbalanced, DC Coupled
Headphone Output Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.08 dB
- Dynamic Range: 116 dB A-Weighted
- THD + Noise: -103 dB (0.0007%) into 300 Ω
- Maximum Output Power at 32 Ω: 45 mW
- Maximum Output Power at 300 Ω: 24 mW
- Connectors: 1/4" and 1/8" TRS Stereo Unbalanced, DC Coupled
System Requirements
- macOS: macOS 12 Monterey or Newer
- Windows: Windows 10 64-Bit or Newer
- iPad / iPhone: iPadOS / iOS 16 or Newer
- Computer Processor: Intel, AMD or Apple Silicon
- Computer Connection: Available USB 2.0 or Higher Port
- Internet Connection: Required for Software Downloads
- DAW Compatibility: Ableton Live, FL Studio, GarageBand, Logic Pro, Pro Tools and Other Major DAWs
