UA-VOLT4MAX
Universal Audio UA Volt 4 Max USB Audio Interface 12-in/6-out
Pay With
Product Information
The Universal Audio Volt 4 Max is a next-generation 12-in / 6-out desktop USB audio interface designed for musicians, producers, engineers, podcasters, and content creators who want professional studio sound with powerful onboard processing and expanded connectivity. Featuring 32-bit / 192 kHz conversion, dual Tone Shaping Preamps, Max compression, speaker switching, a built-in talkback microphone, full-colour Smart Display, Auto-Gain, Clip Protection, ADAT expansion, MIDI I/O, and a comprehensive UAD software bundle, Volt 4 Max is built to become the centre of a modern recording setup.
Built by the same Universal Audio team behind the legendary Apollo interfaces, Volt 4 Max features two digitally controlled mic preamps with 60 dB of available gain and three harmonic character modes — Warmth, Focus, and Shine. These provide Tube, Solid State, and British Class-A-inspired tonal options, allowing vocals and instruments to take on additional colour and character before they reach your recording software.
Max Processing adds onboard real-time compression with six musical presets designed for vocals, guitars, bass, and other sources. Inspired by classic studio compressors including the LA-2A and 1176, Max Processing can be combined with the three Tone Shaping modes to provide more than 18 tonal combinations directly from the interface.
Two mic / line inputs and two front-panel Hi-Z instrument inputs make it easy to record vocals, guitars, basses, and stereo sources, while additional line inputs provide connectivity for outboard equipment. Independent 48V phantom power is available on each microphone channel for condenser microphones.
For larger studio setups, Volt 4 Max includes ADAT or S/PDIF optical input, allowing up to eight additional digital channels at 44.1 or 48 kHz. MIDI In and Out provides convenient connection for keyboards, synthesisers, drum machines, and controllers, while the onboard USB hub can connect and power compatible peripherals.
The full-colour Smart Display provides clear at-a-glance feedback for inputs, levels, settings, and gain reduction. Auto-Gain automatically sets recording levels in seconds, while Clip Protection catches unexpected peaks to help keep recordings clean and distortion-free.
Volt 4 Max also features two stereo monitor outputs with Main and Alt speaker switching, making it easy to compare mixes across two different sets of studio monitors. Two studio-quality headphone outputs provide monitoring for collaboration, while the built-in talkback microphone allows easy communication with performers during recording sessions.
Built-in Loopback makes Volt 4 Max ideal for podcasting, livestreaming, and content creation by allowing live sources to be combined with computer audio. Full integration with the UAD Console app and LUNA provides session recall and low-latency cue mixes for an efficient studio workflow.
Volt 4 Max includes the UAD Volt Studio Bundle and a comprehensive collection of third-party software, giving you professional EQs, compressors, reverbs, guitar and bass amps, instruments, and production tools right out of the box.
Features
- 12-in / 6-out desktop USB audio interface with professional 32-bit / 192 kHz audio conversion
- Two Tone Shaping Preamps with 60 dB of digitally controlled gain
- Three preamp character modes: Warmth, Focus, and Shine
- Warmth mode provides tube-inspired tonal character
- Focus mode provides solid-state-inspired tonal character
- Shine mode provides British Class-A-inspired tonal character
- Max Processing with six onboard real-time compression presets
- Compression presets inspired by classic LA-2A and 1176 studio compressors
- More than 18 tonal combinations using Tone Shaping and Max Processing together
- Two mic / line inputs and two front-panel Hi-Z instrument inputs
- Additional line inputs for external studio equipment
- Independent 48V phantom power on each microphone channel
- Speaker switching between Main and Alt monitor outputs
- Built-in talkback microphone for studio communication
- ADAT or S/PDIF optical input for digital expansion
- Up to eight additional digital input channels via ADAT at 44.1 or 48 kHz
- MIDI In and Out for keyboards, controllers, drum machines, and synthesisers
- Onboard USB hub for connecting and powering compatible peripherals
- Full-colour Smart Display with gain-reduction metering
- Auto-Gain automatically sets suitable recording levels
- Clip Protection helps prevent unexpected peaks from ruining takes
- Two studio-quality headphone outputs with one shared cue mix
- Built-in Loopback for podcasting, streaming, and content creation
- Full integration with UAD Console and LUNA
- Session recall and low-latency cue mix support
- USB bus powered and class compliant
- Compatible with Mac, Windows, iPad, and iPhone
- Rugged desktop construction designed for long-term studio use
Included Software
- LUNA Digital Audio Workstation: Universal Audio's recording, mixing, and mastering environment
- Topline Vocal Tune: Vocal tuning software included with the UAD Volt Studio Bundle
- UA 610 Tube Preamp & EQ Collection: Classic UA tube preamp and EQ emulation
- Century Tube Channel Strip: Tube channel strip for recording and mixing
- Teletronix LA-2A Tube Compressor: Classic optical tube compression
- UA 1176 Classic FET Compressor: Classic FET compression
- Pure Plate Reverb: Plate-style reverb effect
- Galaxy Tape Echo: Vintage-inspired tape echo effect
- Oxide Tape Recorder: Tape recording emulation
- Vibe Analog Machines: Analog-inspired processing tools
- PolyMAX Synth: Polyphonic software synthesiser
- Anthem Analog Synth: Analog-style software synthesiser
- UAD Lion '68 Super Lead Amp: Guitar amplifier plug-in
- UAD Showtime '64 Tube Amp: Vintage-style tube guitar amplifier plug-in
- Melodyne Essential by Celemony: Pitch and timing editing software
- Ampeg SVT-VR Classic Bass Bundle by Plugin Alliance: Includes Ampeg SVT-VR Classic, bx_Tuner, and bx_Masterdesk_Classic
- Virtual Drummer DEEP by UJAM: Virtual drum instrument
- Virtual Bassist DANDY by UJAM: Virtual bass instrument
- Splice INSTRUMENT: Included virtual instrument
- Prisma - Producer Lab by UVI: Included UVI production software
- FL Studio Producer Edition: Three months free
Specifications
- Brand: Universal Audio
- Model: Volt 4 Max
- Product Type: USB Audio Interface
- Simultaneous I/O: 12-In / 6-Out
- Maximum Audio Resolution: 32-Bit / 192 kHz
- Supported Sample Rates: 44.1, 48, 88.2, 96, 176.4 and 192 kHz
- Bit Depth: 32-Bit
- Microphone Preamps: 2
- Microphone Preamp Gain: 60 dB
- Preamp Processing: Tone Shaping, Harmonic Saturation and Max Compression
- Preamp Character Modes: Warmth, Focus and Shine
- Max Processing Presets: 6
- Mic / Line Inputs: 2 x XLR / 1/4" Combo Jack
- Instrument Inputs: 2 x Front-Panel 1/4" TS Hi-Z
- Additional Line Inputs: 2 x 1/4" TRS Balanced or TS Unbalanced
- Phantom Power: +48V Switchable Per Channel
- Monitor Outputs: 2 x Stereo Pairs with Main / Alt Speaker Switching
- Headphone Outputs: 2 x Stereo Outputs with One Shared Cue Mix
- Talkback: Built-In Microphone
- Optical Input: ADAT or S/PDIF
- ADAT Input: 8 Channels at 44.1 / 48 kHz, 4 Channels at 96 kHz, 2 Channels at 192 kHz
- S/PDIF Input: 2 Channels at All Supported Sample Rates
- MIDI: MIDI In / Out
- MIDI Connector: 1/8" TRS Mini-Jack, Type A
- Smart Display: Full-Colour Display with Gain-Reduction Metering
- Auto-Gain: Yes
- Clip Protection: Yes
- Loopback: Yes
- USB Host: USB 2.0
- USB Hub: 1 x Peripheral Port, 5VDC @ 0.5A Maximum
- USB External Power Input: USB Type-C, 5VDC @ 1.5A Minimum
- Included External Power Supply: 5VDC @ 3A
- USB Connector Type: USB Type-C
- USB Bus Powered: Yes
- Power Consumption: 5.5W Typical / 7.1W Maximum
- Power Switch: Rear Panel
Instrument Input Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.02 dB
- Dynamic Range: 116 dB A-Weighted
- THD + Noise: -108 dB (0.0004%)
- Maximum Input Level: 13 dBu
- Input Impedance: 1 MΩ
- Available Gain: 60 dB Digitally Controlled
- Connector: 1/4" TS Unbalanced
Microphone Input Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.08 dB
- Dynamic Range: 119 dB A-Weighted
- THD + Noise: -110 dB (0.0003%)
- Maximum Input Level: 14 dBu
- Input Impedance: 2 kΩ
- Available Gain: 60 dB Digitally Controlled
- Phantom Power: +48V Switchable Per Channel
- Connector: XLR Combo Jack, Pin 2 Positive
Line Input Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.05 dB
- Dynamic Range: 119 dB A-Weighted
- THD + Noise: -108 dB (0.0004%)
- Maximum Input Level: 22 dBu
- Input Impedance: 10 kΩ
- Available Gain: 60 dB Digitally Controlled
- Connector: 1/4" TRS Balanced or TS Unbalanced
Monitor & Line Output Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.05 dB
- Dynamic Range: 126 dB A-Weighted
- THD + Noise: -112 dB (0.0003%)
- Maximum Output Level: 20.2 dBu
- Output Impedance: 200 Ω
- Connector: 1/4" TRS Balanced or TS Unbalanced, DC Coupled
Headphone Output Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.08 dB
- Dynamic Range: 116 dB A-Weighted
- THD + Noise: -103 dB (0.0007%) into 300 Ω
- Maximum Output Power at 32 Ω: 45 mW
- Maximum Output Power at 300 Ω: 24 mW
- Connectors: 1/4" and 1/8" TRS Stereo Unbalanced, DC Coupled
System Requirements
- macOS: macOS 12 Monterey or Newer
- Windows: Windows 10 64-Bit or Newer
- iPad / iPhone: iPadOS / iOS 16 or Newer
- Computer Processor: Intel, AMD or Apple Silicon
- Computer Connection: Available USB 2.0 or Higher Port
- Internet Connection: Required for Software Downloads
- DAW Compatibility: Ableton Live, FL Studio, GarageBand, Logic Pro, Pro Tools and Other Major DAWs
