UA-VOLT4G2
Universal Audio UA Volt 4 Gen 2 USB Audio Interface 12-in/6-out
Pay With
Product Information
The Universal Audio Volt 4 Gen 2 is a next-generation 12-in / 6-out USB audio interface designed for musicians, producers, songwriters, and content creators who need professional studio sound with expanded connectivity. Featuring 32-bit / 192 kHz conversion, dual Tone Shaping Preamps, ADAT and S/PDIF expansion, MIDI I/O, a full-colour Smart Display, Auto-Gain, Clip Protection, and a comprehensive software bundle, Volt 4 Gen 2 provides a powerful recording centre for both mobile and desktop studios.
Built by the same Universal Audio team behind the legendary Apollo interfaces, Volt 4 Gen 2 features two digitally controlled mic preamps with 60 dB of available gain and three selectable character modes — Warmth, Focus, and Shine. These provide Tube, Solid State, and British Class-A-inspired tonal options, allowing you to add character to vocals and instruments directly at the source.
Two studio-grade mic / line inputs and two front-panel Hi-Z instrument inputs make it easy to record vocals, guitars, basses, and stereo sources. Additional line I/O provides connectivity for outboard equipment, while independent 48V phantom power on each microphone channel supports professional condenser microphones.
For larger recording setups, Volt 4 Gen 2 features ADAT or S/PDIF optical input, allowing up to eight additional digital input channels at 44.1 or 48 kHz. MIDI In and Out provides convenient integration with keyboards, drum machines, synthesisers, and controllers, while an onboard USB hub can connect compatible peripherals and power external MIDI devices.
The full-colour Smart Display provides clear visual feedback for inputs, levels, and settings. Auto-Gain automatically sets suitable recording levels in seconds, while Clip Protection catches unexpected peaks so you can concentrate on the performance instead of constantly watching meters.
Built-in Loopback makes Volt 4 Gen 2 suitable for podcasting, livestreaming, video calls, and content creation by allowing live sources to be combined with computer audio. Full integration with the UAD Console app and LUNA also provides session recall and low-latency cue mixes for a streamlined recording workflow.
Volt 4 Gen 2 is USB bus powered and class compliant for straightforward use with compatible Mac, Windows, iPad, and iPhone devices. It also includes the UAD Volt Studio Bundle and a collection of third-party software, giving you professional EQs, compressors, reverbs, guitar and bass amps, instruments, and production tools right out of the box.
Features
- 12-in / 6-out USB audio interface with professional 32-bit / 192 kHz audio conversion
- Two Tone Shaping Preamps with 60 dB of digitally controlled gain
- Three preamp character modes: Warmth, Focus, and Shine
- Warmth mode provides tube-inspired tonal character
- Focus mode provides solid-state-inspired tonal character
- Shine mode provides British Class-A-inspired tonal character
- Two mic / line inputs and two front-panel Hi-Z instrument inputs
- Additional line I/O for connecting outboard studio equipment
- Independent 48V phantom power on each microphone channel
- ADAT or S/PDIF optical input for digital expansion
- Up to eight additional digital input channels via ADAT at 44.1 or 48 kHz
- MIDI In and Out for keyboards, controllers, drum machines, and synthesisers
- Onboard USB hub for connecting peripherals and powering compatible MIDI controllers
- Full-colour Smart Display for clear at-a-glance visual feedback
- Auto-Gain automatically sets suitable recording levels
- Clip Protection helps protect recordings from unexpected signal peaks
- Built-in Loopback for podcasting, streaming, and content creation
- Full integration with UAD Console and LUNA
- Session recall and low-latency cue mix support
- USB bus powered and class compliant
- Compatible with Mac, Windows, iPad, and iPhone
- Rugged construction designed for long-term studio and mobile use
- Includes a comprehensive UAD and third-party software bundle
Included Software
- LUNA Digital Audio Workstation: Universal Audio's recording, mixing, and mastering environment
- Topline Vocal Tune: Vocal tuning software included with the UAD Volt Studio Bundle
- UA 610 Tube Preamp & EQ Collection: Classic UA tube preamp and EQ emulation
- Century Tube Channel Strip: Tube channel strip for recording and mixing
- Teletronix LA-2A Tube Compressor: Classic optical tube compression
- UA 1176 Classic FET Compressor: Classic FET compression
- Pure Plate Reverb: Plate-style reverb effect
- Galaxy Tape Echo: Vintage-inspired tape echo effect
- Oxide Tape Recorder: Tape recording emulation
- Vibe Analog Machines: Analog-inspired processing tools
- PolyMAX Synth: Polyphonic software synthesiser
- Anthem Analog Synth: Analog-style software synthesiser
- UAD Lion '68 Super Lead Amp: Guitar amplifier plug-in
- UAD Showtime '64 Tube Amp: Vintage-style tube guitar amplifier plug-in
- Melodyne Essential by Celemony: Pitch and timing editing software
- Ampeg SVT-VR Classic Bass Bundle by Plugin Alliance: Includes Ampeg SVT-VR Classic, bx_Tuner, and bx_Masterdesk_Classic
- Virtual Drummer DEEP by UJAM: Virtual drum instrument
- Virtual Bassist DANDY by UJAM: Virtual bass instrument
- Splice INSTRUMENT: Included virtual instrument
- Prisma - Producer Lab by UVI: Included UVI production software
- FL Studio Producer Edition: Three months free
Specifications
- Brand: Universal Audio
- Model: Volt 4 Gen 2
- Product Type: USB Audio Interface
- Simultaneous I/O: 12-In / 6-Out
- Maximum Audio Resolution: 32-Bit / 192 kHz
- Supported Sample Rates: 44.1, 48, 88.2, 96, 176.4 and 192 kHz
- Bit Depth: 32-Bit
- Microphone Preamps: 2
- Microphone Preamp Gain: 60 dB
- Preamp Tone Shaping: Warmth, Focus and Shine
- Mic / Line Inputs: 2 x XLR / 1/4" Combo Jack
- Instrument Inputs: 2 x Front-Panel 1/4" TS Hi-Z
- Line Inputs: 4 Total
- Phantom Power: +48V Switchable Per Channel
- Optical Input: ADAT or S/PDIF
- ADAT Input: 8 Channels at 44.1 / 48 kHz, 4 Channels at 96 kHz, 2 Channels at 192 kHz
- S/PDIF Input: 2 Channels at All Supported Sample Rates
- MIDI: MIDI In / Out
- MIDI Connector: 1/8" TRS Mini-Jack, Type A
- Smart Display: Full-Colour Display
- Auto-Gain: Yes
- Clip Protection: Yes
- Loopback: Yes
- Monitor Outputs: 1 x Stereo Pair
- Additional Line Outputs: Line 3-4
- Headphone Output: 1 x Stereo Output with One Cue Mix
- USB Host: USB 2.0
- USB Hub: 1 x Peripheral Port, 5VDC @ 0.5A Maximum
- USB External Power Input: USB Type-C, 5VDC @ 1A Minimum
- USB Connector Type: USB Type-C
- USB Bus Powered: Yes
- Power Consumption: 4.2W Typical / 5.8W Maximum
- Power Switch: Rear Panel
Instrument Input Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.02 dB
- Dynamic Range: 116 dB A-Weighted
- THD + Noise: -108 dB (0.0004%)
- Maximum Input Level: 13 dBu
- Input Impedance: 1 MΩ
- Available Gain: 60 dB Digitally Controlled
- Connector: 1/4" TS Unbalanced
Microphone Input Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.08 dB
- Dynamic Range: 118 dB A-Weighted
- THD + Noise: -110 dB (0.0003%)
- Maximum Input Level: 14 dBu
- Input Impedance: 2 kΩ
- Available Gain: 60 dB Digitally Controlled
- Phantom Power: +48V Switchable Per Channel
- Connector: XLR Combo Jack, Pin 2 Positive
Line Input Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.05 dB
- Dynamic Range: 119 dB A-Weighted
- THD + Noise: -108 dB (0.0004%)
- Maximum Input Level: 22 dBu
- Input Impedance: 10 kΩ
- Available Gain: 60 dB Digitally Controlled on Channels 1 and 2 Only
- Connector: 1/4" TRS Balanced or TS Unbalanced via Combo Jack
Monitor & Line Output Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.05 dB
- Dynamic Range: 126 dB A-Weighted
- THD + Noise: -112 dB (0.0003%)
- Maximum Output Level: 20.2 dBu
- Output Impedance: 200 Ω
- Connector: 1/4" TRS Balanced, DC Coupled
Headphone Output Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.08 dB
- Dynamic Range: 116 dB A-Weighted
- THD + Noise: -103 dB (0.0007%) into 300 Ω
- Maximum Output Power at 32 Ω: 45 mW
- Maximum Output Power at 300 Ω: 24 mW
- Connector: 1/4" TRS Stereo Unbalanced, DC Coupled
System Requirements
- macOS: macOS 12 Monterey or Newer
- Windows: Windows 10 64-Bit or Newer
- iPad / iPhone: iPadOS / iOS 16 or Newer
- Computer Processor: Intel, AMD or Apple Silicon
- Computer Connection: Available USB 2.0 or Higher Port
- Internet Connection: Required for Software Downloads
- DAW Compatibility: Ableton Live, FL Studio, GarageBand, Logic Pro, Pro Tools and Other Major DAWs
