UA-VOLT1G2
Universal Audio UA Volt 1 Gen 2 USB Audio Interface 2-in/2-out
Pay With
Product Information
The Universal Audio Volt 1 Gen 2 is a next-generation 2-in / 2-out USB audio interface designed for singer-songwriters, musicians, podcasters, and content creators who want professional studio sound in a compact, portable setup. Featuring 32-bit / 192 kHz audio conversion, UA's Tone Shaping Preamp, a dedicated Hi-Z instrument input, and a comprehensive software bundle, Volt 1 makes it easy to capture polished recordings wherever inspiration strikes.
Built by the same team behind Universal Audio's renowned Apollo interfaces, Volt 1 Gen 2 delivers detailed, professional-quality recording with straightforward hands-on controls. Its Tone Shaping Preamp provides 60 dB of available gain and three character modes — Warmth, Focus, and Shine — allowing you to add Tube, Solid State, or British Class-A-inspired tonal character to vocals and instruments at the push of a button.
Professional 32-bit / 192 kHz converters preserve the detail and dynamics of every performance, while the studio-quality headphone and monitor outputs provide clear, confident monitoring throughout recording and mixing. A 48V phantom-powered mic input supports condenser microphones, while the front-panel Hi-Z instrument input makes it easy to connect guitars and other instruments directly.
Volt 1 Gen 2 is USB bus powered, allowing you to create without an external power supply when used with a compatible device. Class-compliant operation provides straightforward connectivity with Mac, Windows, iPad, and iPhone, while compatibility with major DAWs means you can work in the production software you already know.
Built-in Loopback makes Volt 1 Gen 2 ideal for podcasts, livestreams, video calls, and content creation by allowing live input sources to be blended with computer audio. It also works with the UAD Console app and Universal Audio's LUNA Digital Audio Workstation for an integrated recording and production workflow.
Volt 1 Gen 2 includes a premium collection of UAD plug-ins, instruments, and third-party software, including LUNA, UA 610 Tube Preamp & EQ Collection, Teletronix LA-2A Tube Compressor, UA 1176 Classic FET Compressor, guitar and bass amp plug-ins, virtual instruments, and more, giving you a complete creative toolkit right out of the box.
Features
- 2-in / 2-out USB audio interface for music recording, podcasting, streaming, and content creation
- Professional 32-bit / 192 kHz audio conversion
- Tone Shaping Preamp with 60 dB of available gain
- Three preamp character modes: Warmth, Focus, and Shine
- Warmth mode provides tube-inspired character
- Focus mode provides solid-state-inspired tonal character
- Shine mode provides British Class-A-inspired tonal character
- Mic / line input plus dedicated front-panel Hi-Z instrument input
- 48V phantom power for condenser microphones
- Studio-quality headphone output for clear monitoring
- Stereo monitor outputs for connecting powered studio monitors
- Built-in Loopback for podcasting, livestreaming, and content creation
- Works with the UAD Console app and LUNA Digital Audio Workstation
- USB bus powered for portable recording
- USB class-compliant operation
- Compatible with Mac, Windows, iPad, and iPhone
- Works with major DAWs including Ableton Live, FL Studio, GarageBand, Logic Pro, and Pro Tools
- Rugged construction designed for long-term studio and mobile use
- Includes a comprehensive collection of UAD plug-ins, instruments, and third-party software
Included Software
- LUNA Digital Audio Workstation: Universal Audio's recording, mixing, and mastering environment
- Topline Vocal Tune: Vocal tuning software included with the UAD Volt Studio Bundle
- UA 610 Tube Preamp & EQ Collection: Classic UA tube preamp and EQ emulation
- Century Tube Channel Strip: Tube channel strip for recording and mixing
- Teletronix LA-2A Tube Compressor: Classic optical tube compression
- UA 1176 Classic FET Compressor: Classic FET compression
- Pure Plate Reverb: Plate-style reverb effect
- Galaxy Tape Echo: Vintage-inspired tape echo effect
- Oxide Tape Recorder: Tape recording emulation
- Vibe Analog Machines: Analog-inspired processing tools
- PolyMAX Synth: Polyphonic software synthesiser
- Anthem Analog Synth: Analog-style software synthesiser
- UAD Lion '68 Super Lead Amp: Guitar amplifier plug-in
- UAD Showtime '64 Tube Amp: Vintage-style tube guitar amplifier plug-in
- Melodyne Essential by Celemony: Pitch and timing editing software
- Ampeg SVT-VR Classic Bass Bundle by Plugin Alliance: Includes Ampeg SVT-VR Classic, bx_Tuner, and bx_Masterdesk_Classic
- Virtual Drummer DEEP by UJAM: Virtual drum instrument
- Virtual Bassist DANDY by UJAM: Virtual bass instrument
- Splice INSTRUMENT: Included virtual instrument
- Prisma - Producer Lab by UVI: Included UVI production software
- FL Studio Producer Edition: Three months free
Specifications
- Brand: Universal Audio
- Model: Volt 1 Gen 2
- Product Type: USB Audio Interface
- Simultaneous I/O: 2-In / 2-Out
- Maximum Audio Resolution: 32-Bit / 192 kHz
- Supported Sample Rates: 44.1, 48, 88.2, 96, 176.4 and 192 kHz
- Bit Depth: 32-Bit
- Microphone Preamp: 1
- Microphone Preamp Gain: 60 dB
- Preamp Tone Shaping: Warmth, Focus and Shine
- Phantom Power: +48V Switchable
- Instrument Input: 1 x 1/4" TS Unbalanced Hi-Z
- Mic / Line Input: 1 x XLR / 1/4" Combo Jack
- Monitor Outputs: 1 x Stereo Pair
- Monitor Output Connector: 1/4" TRS Balanced
- Headphone Output: 1 x Stereo 1/4" TRS
- Loopback: Yes
- Digital / Optical I/O: None
- MIDI: None
- USB: USB 2.0
- USB Connector Type: USB Type-C
- USB External Power Input: USB Type-C, 5VDC @ 1A Minimum
- USB Bus Powered: Yes
- Power Consumption: 2.4W Typical / 3.6W Maximum
- On / Off Switch: None
Instrument Input Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.03 dB
- Dynamic Range: 116 dB A-Weighted
- THD + Noise: -101 dB (0.0009%)
- Maximum Input Level: 12.5 dBu
- Input Impedance: 1 MΩ
- Available Gain: 60 dB
- Connector: 1/4" TS Unbalanced
Microphone Input Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.1 dB
- Dynamic Range: 119 dB A-Weighted
- THD + Noise: -108 dB (0.0004%)
- Maximum Input Level: 14.5 dBu
- Input Impedance: 2 kΩ
- Available Gain: 60 dB
- Phantom Power: +48V Switchable
- Connector: XLR Combo Jack, Pin 2 Positive
Line Input Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.05 dB
- Dynamic Range: 119 dB A-Weighted
- THD + Noise: -108 dB (0.0004%)
- Maximum Input Level: 22 dBu
- Input Impedance: 10 kΩ
- Available Gain: 60 dB
- Connector: 1/4" TRS Balanced or TS Unbalanced via Combo Jack
Monitor Output Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.04 dB
- Dynamic Range: 122 dB A-Weighted
- THD + Noise: -111 dB (0.0003%)
- Maximum Output Level: 20.2 dBu
- Output Impedance: 100 Ω
- Connector: 1/4" TRS Balanced, DC Coupled
Headphone Output Specifications
- Frequency Response: 20 Hz – 20 kHz ±0.1 dB
- Dynamic Range: 121 dB A-Weighted
- THD + Noise: -108 dB (0.0004%) into 300 Ω
- Maximum Output Power at 32 Ω: 52 mW
- Maximum Output Power at 300 Ω: 27 mW
- Connector: 1/4" TRS Stereo Unbalanced, DC Coupled
System Requirements
- macOS: macOS 12 Monterey or Newer
- Windows: Windows 10 64-Bit or Newer
- iPad / iPhone: iPadOS / iOS 16 or Newer
- Computer Processor: Intel, AMD or Apple Silicon
- Computer Connection: Available USB 2.0 or Higher Port
- Internet Connection: Required for Software Downloads
- DAW Compatibility: Ableton Live, FL Studio, GarageBand, Logic Pro, Pro Tools and Other Major DAWs
