Product Information:
WORTH IT EVERY TIME
For over two decades, keyboard players everywhere have relied on
Roland’s KC amps for their powerful high-fidelity sound, onboard
mixing features, versatile connectivity, and lasting durability. The
latest generation carries on the time-honored KC benchmark of
quality while offering new enhancements tuned for the needs of
today’s working musicians. With a KC amp by your side, you’re in
complete control of your stage rig, so you’ll always sound great and
play your best. And that’s worth it every time.
Packed with many new design features, the KC-600 updates the
previous-generation KC-550, Roland’s top-selling keyboard amp. The
power has been increased to 200 watts, and the two-way speaker
system features a newly designed 15-inch custom woofer for improved
sound quality. In addition, the power section has been completely
redesigned for better stability, enhanced bass reproduction, and
reduced weight. With the KC-600’s built-in mixer, you’re able to
connect a variety of stereo keyboards and instruments, plus an XLR
vocal mic. And via the Stereo Link function, you can easily chain a
second KC-600 for more inputs and true stereo amplification on
stage.
Compact and versatile keyboard amplifier with
200 watts of power
Redesigned power amp and universal power supply provide increased stability,
improved bass reproduction, and reduced weight
Custom two-way speaker system with newly developed 15-inch woofer and horn
tweeter
Onboard mixer with four stereo input channels, stereo auxiliary input, and
master EQ with Shape switch
Output Select function on Channel 4 for monitoring click and guide tracks
XLR mic input, XLR and ¼-inch line outputs, headphones output, and sub output
Chain another KC-600 with the Stereo Link function for more inputs and true
stereo sound on stage
Metal jacks for increased durability
Removable casters included
Full-Range Sound for Keyboards and Electronic Musical Instruments
The KC-600 offers powerful, punchy sound and full-range audio reproduction in a
compact amp with 200 watts of power. The cabinet features Roland’s patented twin
bass-reflex design, providing extended low-frequency response without
distortion. Paired with the newly redesigned power section, the KC-600 delivers
even better bass performance for amplifying 88-note stage pianos, organs, and
synthesizers, plus rhythm machines and other electronic instruments. An added
benefit of the efficient new power section is reduced weight, making the KC-600
easier to carry from gig to gig.
Onboard Stereo Mixing
Via the KC-600’s four line input channels, you can connect keyboards, percussion
pads, drum machines, and more. There’s also a dedicated auxiliary input to plug
in a smartphone or music player for backing tracks. The line and aux inputs
support stereo connections, allowing you to send stereo sound to a PA or
recording device, and also amplify in stereo when connecting a second KC-600
through Stereo Link. Channel 1 includes an XLR input too, letting you plug in a
vocal mic for even more versatility. And with the convenient Output Select
function on Channel 4, there’s lots of flexibility for monitoring click and
guide tracks while performing.
Versatile Connectivity for Performing, Recording, and Practice
With its easy-access connectivity, the KC-600 integrates into any playing
environment. Stereo line outputs are provided on both XLR and 1/4-inch jacks,
offering simultaneous connections for interfacing with PA systems, stage
monitors, and recording devices. There’s also a Sub Out jack for connecting to a
powered subwoofer, with level conveniently tied to the amp’s master volume for
one-touch control. The KC-600 has a headphones jack as well, perfect for silent
practice sessions and discrete stage monitoring.
Expand Your Setup with Stereo Link
If you ever want to expand your inputs or monitor in stereo, the KC-600’s Stereo
Link function makes it simple. First off, the number of available inputs doubles
when you connect to the two stereo link jacks on a second KC-600. In addition,
the left and right signals of connected stereo instruments are split across the
two amps, allowing you to bring a studio-like monitoring experience to your
stage performance setup..
Specifications:
Rated Power Output200 WNominal Input Level (1
kHz)CH1 (BALANCED, L/MONO, R): -50-- -20 dBu
CH2 (L/MONO, R): -20 dBu
CH3 (L/MONO, R): -20 dBu
CH4/MONITOR IN (L/MONO, R): -20 dBu
AUX IN (L, R, STEREO): -10 dBu
STEREO LINK (IN): 0 dBuNominal Output Level (1 kHz)LINE OUT (L/MONO, R): +4 dBu
LINE OUT (BALANCED L, R): +4 dBu
STEREO LINK (OUT): 0 dBu
SUB OUT: +4 dBuSpeakers38 cm (15 inches) Woofer x 1
Horn Tweeter x 1ControlsSHAPE button
POWER switch
GND LIFT switch
[CH1]
MIC/LINE knob
[CH2]
LINE knob
[CH3]
LINE knob
[CH4]
LINE knob
OUTPUT SEL knob
[AUX IN]
LEVEL knob
[PHONES]
VOLUME knob
[EQUALIZER]
LOW knob
MIDDLE knob
HIGH knob
MASTER knobIndicatorPowerConnectorsCH1 (BALANCED) jack: XLR type
CH1 (L/MONO, R) jacks: 1/4-inch phone type
CH2 (L/MONO, R) jacks: 1/4-inch phone type
CH3 (L/MONO, R) jacks: 1/4-inch phone type
CH4/MONITOR IN (L/MONO, R) jacks: 1/4-inch phone type
LINE OUT (L/MONO, R) jacks: 1/4-inch phone type
LINE OUT (BALANCED L, R) jacks: XLR type
AUX IN (L, R) jacks: RCA phono type
AUX IN (STEREO) jacks: Stereo miniature phone type
SUB OUT jack: 1/4-inch phone type
STEREO LINK (IN, OUT) jacks: 1/4-inch phone type
PHONES jack: Stereo 1/4-inch TRS phone type (mono signal output)Power
Consumption50 WAccessoriesOwner's Manual
Caster x 4SIZE AND WEIGHTWidth590 mm
23-1/4 inchesDepth445 mm
17-9/16 inchesHeight (including casters)590 mm
23-1/4 inchesHeight (excluding casters)536 mm
21-1/8 inchesWeight29 kg
63 lbs 15 oz
