The New Bandmate for Today s Modern
A Quick Look at Loop Core Deluxe
With upgraded hardware, the new Loop Core Deluxe allows you to
record loop phrases up to 8 hours with unlimited layers in 24-bit
high-resolution audio quality into 99 saved memories.
Loop Core Deluxe`s Drum Rhythm
Nothing feels better than playing your guitar along with realistic
drum rhythms. Loop Core Deluxe’s all-new drum machine comes with 40
different drum rhythms (30 in 4/4, 10 in 3/4) covering different
styles of genres including rock, pop, blues, jazz and much more.
To finish your playing, you can choose 3 different modes:
1- NORMAL MODE: Double tap - Instant Stop
2- FINISH MODE: Plays until the end of the last measure
3- FADE OUT MODE: 10 seconds Fade-Out
Importing and Backing up Your Loop Phrases
Connect your Loop Core Deluxe to your PC/Mac with a Mini-B USB
connector to import available loop phrases or to back up yours. Loop
Core Deluxe is only compatible with 24-bit/44.1kHz WAV files.
Loop Core Deluxe Bundle
The LOOP CORE BUNDLE includes the additional NMP-2 DUAL Footswitch
which is absolutely the easiest way to switch between loop phrases.
Your recordings for verse, chorus, and bridge parts, can now be
seamlessly accessed utilizing the convenient DUAL footswitch.
Frequency Compensation & Cabinet Simulation
To ensure the exact tone you desire, Loop Core Deluxe is designed with frequency
compensation for drums and a cabinet simulator. Both are utilized through the
stereo output Jacks.
Stereo Output Connection Ways
When using Loop Core Deluxe in the same situation as pictured below, it will
detect the type of devices connected. The original guitar tone and loop phase
will output to guitar amplifier while drum machine sound output to the mixer. To
active this feature: please press down RHYTHM button before powering on the
device and "F3" appears on the screen as shown in the below drawing.
The Stereo Output has serval options: to amp, output guitar signal or to mixer,
drum machine out. Loop Core Deluxe will detect the type of the device you are
using and the original guitar tone and loop phase will output to your guitar
amplifier while the drum machine sound will output to the mixer.
True Bypass or Buffer Bypass
Loop Core Deluxe is designed with a switchable buffer bypass and true bypass.
The choice is yours! Already, have a buffer bypass pedal? Use it! This system
fits your needs.
Just hold down the [STOP MODES] Button while plug in the power adapter to switch
in between the 2 bypass modes.
Automatic Tempo Detection
Loop Core users are already familiar with the many hidden treasures of our
original Loop Core such as automatic tempo detection. You can easily lay down a
loop w/out a metronome or any drum patterns. Add a drum pattern later, and Loop
Core Deluxe will automatically process your tempo to match the pattern. No
technical details to fumble with; just enjoy your music!
Loop Core Deluxe vs Original Loop Core:
* Better recording sound quality (24-bit vs. 16-bit)
* Longer recording time (8 hours vs. 6 hours)
* Upgraded drum machine with more realistic drum sounds
* Equipped with NMP-2 Dual Footswitch control pedal for ultimate user experience
* Frequency compensation & cabinet simulation
Put your own music into Loop Core Deluxe
You can convert any audio file to make it compatible for Loop Core Deluxe. You
can download the Nux Audio Converter software free. (Check the support page)
Sampling Rate 44.1K
A/D converter 24bit
Signal Processing 24bit
Frequency response 20Hz—20KHz
Noise Level -98dBu
Dynamic Range 101dB
Power Consumption 65mA - 70mA
Outputs Amplifier Out, Mixer Out (Cabin Simulated)
Display LED & LED Segment Displays
Power 9V DC Negative Tip / 9V Battery
Dimensions 122(L) x 72(W) x 47(H) mm
1 Year Warranty
