Product Information

Premium Fret Edge Treatment

Premium Fret Edge Treatment offer super smooth,comfortable performance.

Aguilar® DCB pickups

The Aguilar® DCB pickups use the dual-ceramic bar design to capture all the detail and character of your tone. The pickup’s uniform magnetic field ensures that no information is lost, making this a great pickup for dynamic playing styles.

MR5S bridge

The MR5S bridge has adjustable saddles for variable string spacing by +/- 1.5mm, answering every bassist’s specific string spacing needs.

Ibanez Custom Electronics 3-band EQ w/EQ bypass switch & Mid frequency switch

Ibanez Custom Electronics 3-band EQ is our latest refinement on the concept of simple, straightforward, no-nonsense EQ control. The Boost and Cut for the Mid Control are each centered on slightly different frequencies, an innovation that delivers a preset range of the most favorable bass tones.
Precision tonal control, including a switch to choose passive-only operation. When the EQ bypasses activated, the treble tone control knob becomes the global tone control for the passive circuit.

Panga Panga fretboard

Panga Panga features a beautiful wood grain which produces a tight low and mid range, along with a sharp attack on high end.

Specifications

• • neck type
  • BTB69pc Maple/Bubinga/Panga Panga w/Graphite reinforcement rodsNeck-through

  • top/back/body
  • Bubinga topBubinga backAsh wing body

  • fretboard
  • Bound Panga Panga fretboardAbalone off-set dot inlay

  • fret
  • Medium Stainless Steel fretsPremium fret edge treatment

  • number of frets
  • 24 (+ zero fret)

  • bridge
  • MR5S bridge

  • string space
  • 17mm

  • neck pickup
  • Aguilar® DCB neck pickupPassive

  • bridge pickup
  • Aguilar® DCB bridge pickupPassive

  • equaliser
  • Ibanez Custom Electronics 3-band EQ w/ EQ bypass switch (passive tone control on treble pot), 3-way Mid frequency switch

  • factory tuning
  • 1C,2G,3D,4A,5E,6B

  • strings
  • D'Addario® NYXL32130SL

  • string gauge
  • .032/.045/.065/.80/.100/.130

  • nut
  • Plastic nut

  • hardware color
  • Gold

• NECK DIMENSIONS

  • • Scale :
    • 889mm
    • a : Width
    • 54mm at NUT
    • b : Width
    • 85mm at 24 (+ zero fret)F
    • c : Thickness
    • 20mm at 1F
    • d : Thickness
    • 22mm at 12F
    • Radius :
    • 950mmR
