Behringer WAVE 8-Voice Multi-Timbral Hybrid Synthesizer

Specifications

Synthesizer Architecture

• Type: Hybrid
• Number of voices: 8
• Type of oscillators: Wavetable
• Number of oscillators: 16
• Filter: 24 dB lowpass

Connectivity

• USB (MIDI): USB 2.0, type B
• MIDI In/out/thru: 5-pin DIN / 16 channels
• Main Output: 2 x 6.35 mm (1/4") TS, unbalanced, max. +22 dBu
• Impedance: 50 Ω
• Channel out: 8 x 6.35 mm (1/4") TS, unbalanced, max. +22 dBu
• Headphones: 1/4" TRS, stereo, max 25 mW
• Impedance: 8 Ω
• Sync in: 6.35 mm (1/4") TRS
• Sync out: 6.35 mm (1/4") TRS
• CV in: 6.35 mm (1/4") TS
• Gate In: 6.35 mm (1/4") TS
• Expression pedal: 6.35 mm (1/4") TRS – voltage send on tip
• Sustain pedal: 6.35 mm (1/4") TS

USB

• Type: Class compliant USB 2.0, type B
• Supported operating systems: Windows 7 or higher / Mac OS X 10.10 or higher

Keyboard and Controls

• Keyboard: 49 semi-weighted, full-size keys, velocity and aftertouch
• Wheels: Pitch, Modulation
• Controls: Octave down / up
• LED: Octave -2/-1/0/1

Volume Section

• Controls: Basis (mono to stereo)
• Master volume

LFO Section

• Controls: Delay
• Waveshape: triangle, sawtooth, ramp, square
• Rate

ADSR Envelope 1 Section

• Controls: Attack
• Decay
• Sustain
• Release

Modifiers Section

• Controls: VCF Cutoff
• VCF Emphasis
• Waves Osc
• Waves Sub

AD Envelope 3 Section

• Controls: Attack 3
• Decay 3
• Env 3 Att

ADSR Envelope 2 Section

• Controls: Attack
• Decay
• Sustain
• Release

Modifiers Controls

• Controls: ENV 1 VCF
• ENV 2 Loudness
• ENV 1 Waves

Display and Controls

• Buttons: Program, Digital, Tuning, Analog, Group
• Shift, Rest/Tie (Settings), Record (Append), Stop (Clear Last), Play/Pause (Restart)
• Numeric Keypad: 0-9, cursor left, cursor right
• Digital Encoder: Data Entry Encoder (press to enter)
• Main Display: 2 x line, 40-digit LCD display
• Secondary Display: 2.5 cm x 1.5 cm OLED
• LED: Group A / B

Power Requirements

• Mains connector: Standard IEC C13 receptacle
• Power consumption: 20 W max
• Internal switch-mode PSU: Autorange 100-240 V, (50/60 Hz)

Physical

• Standard operating temperature range: 5°C – 45°C (41°F – 113°F)
• Dimensions (H x W x D): 112 x 796 x 257 mm (4.01 x 31.34 x 10.12")
• Weight: 7.26 kg (16.0 lbs)
