PCC-160

AKG PCC-160 Boundary Layer Microphone Stage Floor Mic

Pay With AfterPay Zip

Product Information:

GREAT ACT

theater on stage

The PCC160 is a professional boundary layer microphone and an industry standard stage floor microphone. It´s capable of withstanding up to 120dB SPL without distortion. A bass-tilt switch allows the user to tailor the low-end response for particular applications.

PCC® (Phase Coherent Cardioid®) technology uses diaphragms so small that any phase cancellations are above the audible range. This results in a wide, smooth frequency response free of phase interference. The PCC160 uses a supercardioid polar pattern that improves gain before feedback and reduces unwanted room noise from the rear.

Supercardioid polar pattern
for impressive gain before feedback

PCC® (Phase Coherent Cardioid®) technology
for a wide, smooth frequency response

Three-position bass-tilt switch
for optimized body noise suppression

Extremely low profile
for inconspicuous placement on the stage floor

Finely crafted, rugged housing
to withstand the rigors of the stage

Specifications:

General
Audio frequency bandwidth 50 to 18000 Hz
Equivalent noise level 22 dB-A
Sensitivity 22 mV/Pa
Signal to Noise 72 dB-A
Recommended load impedance 2000 Ohms
Powering Interface
Voltage 12 to 48 V
Audio Output
Type Switchcraft TA3F
Contacts 3-pin
Design
Finish black
Dimensions / Weight
Length 170 mm
Width 80 mm
Height 20 mm

Warranty

1 Year (Extended to 3 Years via Registration) Warranty
