Two Notes Opus Multi Channel Amp Sim and DynIR Pedal

Specifications

Input / Output

• Amp/Inst/Line Input: 1/4″ jack unbalanced (TRS)
• Input Impedance:
  • AMP: 160kΩ unbalanced / 300kΩ balanced
  • LINE: 37kΩ unbalanced / 55kΩ balanced
  • INST.: 1MΩ unbalanced
• Max Level (No Input Pad):
  • AMP: 26.1dBu
  • LINE: 11.3dBu
  • INST.: 2.8dBu
• Max Level (With Input Pad):
  • AMP: 36.2dBu
  • LINE: 20.8dBu
  • INST.: 12.3dBu
• Max Admissible Power For Amplifier Connection:
  • “IN LEVEL” Switch Set To “AMP”
  • “TO SPEAKER” output connected to a speaker rated at 16Ω
    • No input pad: 15.2W
    • With input pad: 100W
  • “TO SPEAKER” output connected to a speaker rated at 8Ω
    • No input pad: 15.2W
    • With input pad: 100W
  • “TO SPEAKER” output connected to a speaker rated at 4Ω
    • No input pad: 60.5W
    • With input pad: 100W
• Aux In: 1/8″ (3.5mm) TRS jack
  • Input Impedance: 29kΩ
• TO SPEAKER Output*: 1/4″ Jack balanced (TS)
  • *Unprocessed, unbuffered
• DI Output*: XLR balanced
  • Max level: 10dBu
  • Output Impedance: 600Ω
  • *Protected against +48V phantom power
• Line Output*: XLR balanced
  • Max level: 10dBu
  • Output Impedance: 600Ω
  • *Not Protected against +48V phantom power
• Headphone Output*: 1/8″ (3.5mm) TRS jack
  • Max output power: 300mW under 100Ω
  • Output impedance: 33Ω
• USB Connector: USB-C 2.0
• Memory Card: 256Mb Micro-SD included (Up to 32Gb cards supported)

Digital Audio

• AD/DA Converters: Studio-grade 24-bit / 96 kHz
• Bandwidth (-1dB): 30 Hz – 19 kHz
• Dynamic Range ratio: 101dB
• Internal Processing: 32-bit floating-point
• Latency: 2.2 ms (Line Input to Line Output)

Power

• Power input connector:
  • Connector: 2.1mm x 5.5mm
  • Polarity: Center negative
  • Voltage: 12V DC
  • Current: 200mA
• Supplied adapter:
  • Connector: 2.1mm x 5.5mm
  • Polarity: Center negative
  • Input Voltage: 100-240V AC, 50-60Hz
  • Output Voltage: 12Vdc
  • Max. Current: 2000 mA
• Power consumption: approx. 2W
